#Psoc software drivers#
It provides driver source code you use to customize drivers for an application. The PDL occupies the space between application code and the hardware IP blocks (peripherals). Although called the Peripheral Driver Library it contains much more than driver source code.
#Psoc software software#
PDL is the software development kit for the PSoC 6 family of devices.
Documentation on other parts of the overall software development kit are in there respective references, such as the Bootloader SDK API Reference and the BLE API Reference. This PDL API Reference covers the peripheral drivers. This introduction covers some high level concepts that help you understand and use the PDL to accomplish these tasks. In addition, you must configure clocks, GPIO, and interrupts, as well as route signals from one peripheral to another. To successfully develop software for the PSoC 6 family of devices, you must configure the peripherals to implement desired behavior. Include cy_pdl.h in your source code to use the library.
#Psoc software download#
Download it from and add cy_utils.h to the include search path. The PowerPSoC family integrates four constant-current regulators and four 32V MOSFETs with a PSoC.PDL depends on the Core Library. The PowerPSoC family of integrated embedded power controllers is a single-chip solution for both controlling and driving high-power LEDs. TrueTouch devices support projected capacitive touchscreens, which offer better optical clarity and are more durable and reliable than touchscreens based on resistive technology. The PSoC-based TrueTouch touchscreen solution interprets up to 10 inputs from all areas of the screen simultaneously. The PSoC-based CapSense capacitive sensing function offers single-chip integration of multiple buttons, sliders, touchpads, and proximity detectors, requiring no external components for sensing.
#Psoc software free#
Cypress offers free online PSoC training. Developers can save as much as $10 in system costs. A single PSoC device can integrate as many as 100 peripheral functions. The tool automatically routes all on-chip signals and can even direct I/O to the optimum pins if desired. The PSoC Creator development tool provides a library of dozens of pre-configured analog and digital peripherals that can be dropped into the schematic design canvas and combined into powerful systems.
All PSoC devices are also dynamically reconfigurable, enabling designers to morph internal resources on-the-fly, utilizing fewer components to perform a given task. The flexible PSoC resources allow designers to make firmware-based changes during design, validation, production, and in the field. The original PSoC 1 architecture is based on a cost-optimized M8C 8-bit microprocessor and includes up to 32-kbytes of Flash memory, 2-kbytes of SRAM, an 8x8 multiplier with 32-bit accumulator, power and sleep monitoring circuits, and hardware I☬ communications. PSoC Creator introduces a concurrent hardware/software design paradigm, accepting both schematic and hierarchical input. The PSoC 3 and PSoC 5 design platforms enable simplified migration from 8- to 16- to 32-bits with the newly released PSoC Creator design software.
The two new architectures feature high-precision integrated analog with 20-bit resolution and a PLD-based digital system with up to 48 cascading datapaths. The newly introduced PSoC 3 architecture is based on an 8-bit 8051 processor, and the PSoC 5 architecture includes a 32-bit ARM Cortex-M3 processor. PSoC devices integrate configurable analog and digital circuits, controlled by an on-chip microcontroller, providing both enhanced design revision capability and component count savings. PSoC devices employ a configurable system-on-chip architecture for embedded control design, offering a flash-based equivalent of a field-programmable ASIC without lead-time or NRE penalties.
